OSMO MOBILE 3 User Manual
Not nal
8
© 2019 DJI OSMO All Rights Reserved.
The dierences between the head and shoulder tracking and face track are that head and shoulder
tracking supports 360° tracking while face tracking does not. Also, the detection range of the camera
are dierent. The detection range between the back camera and the gesture is 0.5 to 3 m, and the
distance between the front camera and the gesture is 0.5 to 2 m.
Note that ActiveTrack 3.0 may increase the power consumption and the temperature of the mobile
phone. See the DJI Mimo App section for more information.
6. Zoom Slide
Push up or down to zoom in or out. Push the slider to the T position to enlarge the subject and push
the slider to the W position to shrink.
8. USB-C Charging Port
Charge Osmo Mobile 3 by connecting a USB adapter to this port. Refer to the Charging section for
more information.
9. USB-A Port
The USB-A port can be used to charge mobile phones.
10. 1/4”-20 UNC Port
The 1/4"-20 UNC port can be used to attach a tripod.
7. Trigger
Press and hold to enter lock mode. In lock mode, the gimbal will not follow the handle movements.
Release to exit lock mode.
When ActiveTrack 3.0 is enabled in DJI Mimo, press once to start or stop ActiveTrack 3.0.
Press twice to recenter the gimbal. When using ActiveTrack 3.0, the gimbal will recenter to the center
of the camera view.
Press three times to switch between front and back cameras.
Press once, and then press and hold to enter Sport mode. Release to exit. In Sport mode, the follow
speed of the gimbal increases for capturing quick movements.
