Specifications
General
Gimbal Dimensions
Unfolded: 262.5×119.5×104 mm (L×W×H)
Folded: 167×108.5×46.5 mm (L×W×H)
Weight
Gimbal: Approx. 352 g
Magnetic Phone Clamp: Approx. 31 g
Compatible Phone Weight 170-290 g
Compatible Phone Thickness 6.9-10 mm
Compatible Phone Width 67-84 mm
Battery
Type 18650 Li-ion
Chemical System LiNiMnCoO2
Capacity 2600 mAh
Energy 9.36 Wh
Voltage 2.75-4.2 V
Charging Temperature 5° to 40° C (41° to 104° F)
Operating Temperature 0° to 40° C (32° to 104° F)
Operating Time
Approx. 8 hours (under ideal conditions with the gimbal
fully balanced)
Charging Time
Approx. 2 hours and 12 minutes (measured with a 10W
USB-C charger)
Gimbal Charging Port USB-C
Power Output Port N/A
Bottom Port 1/4"-20 Screw Hole
Gimbal
Power Consumption 1 W (under ideal conditions with the gimbal fully balanced)
Controllable Range
Pan: -115° to 115°
Roll: -85° to 160°
Tilt: -43° to 53°
Mechanical Range
Pan: -161.2° to 171.95°
Roll: -136.7° to 198°
Tilt: -106.54° to 235.5°
Max Control Speed 120°/s
Wireless Mode
Model Bluetooth 5.1
Other
App DJI Mimo
Grip Tripod
Dimensions
Length: 138 mm
Diameter: 32 mm
Weight Approx. 72 g
