dji OSMO MOBILE SE User Manual

4
©
2022 DJI All Rights Reserved.
Introduction
Boasting 3-axis stabilization, the lightweight Osmo Mobile SE unlocks the full potential
of your mobile phone. The foldable magnetic design makes setup easier than ever,
transportation and storage more convenient. Osmo Mobile SE can be operated in both
portrait and landscape, while the upright, underslung, side grip, and low position modes
help capture the perfect shot. Take content to the next level through DJI Mimo with
ActiveTrack
TM
5.0, DynamicZoom, and Pano. The Story mode, Timelapse, and ShotGuides
provide step-by-step tutorials according to the scenario and help generate a video that
can be shared on social media.
Overview
1. Magnetic Phone Clamp 3
2. Roll Motor
3. M3×0.5 Screw Hole
4. Pan Motor
5. Status Panel
6. Joystick
7. Zoom Slider
8. 1/4"-20 UNC Port
9. Charging Port (USB-C)
10. Switch Button
11. Shutter/Record Button
12. Power/M Button
13. Tilt Motor
14. Trigger
Osmo Mobile SE is compatible with DJI OM Fill Light Phone Clamp, which can be
purchased in the DJI Store.
1
2
3
4
7
5
9
10
11
12
13
14
6
8

dji OSMO MOBILE SE Specifications

General

Type	Smartphone camera stabilizer
Foldable	Yes
Material	-
Pan range	-161.2 - 171.95 °
Product color	Grey, White
Number of axis	3
Tilt angle range	-106.54 - 235.5 °
Maximum device depth	10 mm
Maximum device width	84 mm
Minimum device depth	6.9 mm
Minimum device width	67 mm
Maximum weight capacity	0.29 kg
Operating time	8 h
Battery capacity	2600 mAh
Operating temperature (T-T)	0 - 40 °C
Bluetooth version	5.1

Weight and Dimensions

Depth	262.5 mm
Width	119.5 mm
Height	104 mm
Weight	352 g
Dimensions folded (WxDxH)	108.5 x 167 x 46.5 mm
