dji Phantom 2 Vision + - Regaining Control During Failsafe Procedure

©2014 DJI Innovations. All Rights Reserved.50 |
The flight control system will automatically control the aircraft to fly back to the home point and land.
The figure below demonstrates the complete Failsafe landing process when the aircraft entered the Failsafe from
the “Ready to Fly” status.
1
Record H om e Point.
2
F ly in g .
3 Rem ote controller signal lost.
5 Fly back to hom e point.4 S ig n a l lo s t la s t s 3s, begin to go hom e.
6 Landing after hovering 15 s.
LED Flight Indicator
à
OFF CAM ON WIFI ON
MICRO SD
OFF CAM ON WIFI ON
MICRO SD
OFF CAM ON WIFI ON
MICRO SD
OFF CAM ON WIFI ON
MICRO SD
OFF CAM ON WIFI ON
MICRO SD
OFF CAM ON WIFI ON
MICRO SD
OFF CAM ON WIFI ON
MICRO SD
LED Flight Indicator
LED Flight Indicator
LED Flight Indicator LED Flight Indicator LED Flight Indicator
H eight over hom e point<=20m
H eight over hom e point>20 m
20m
E le v a te to 20m
1)
To ensure the aircraft can successfully return to the home point in the Failsafe mode after it
lost the connection from the remote controller, only takeoff the aircraft when it is in the “Read
to Fly” status.
2)
The aircraft will automatically descent during the Failsafe process, if there are less than 6 GPS
satellites are detected for more than 20 seconds.
3)
The aircraft cannot avoid obstacle during Failsafe.
Quickly flipping the S2 switch of the remote controller from upper most to lower most positions 5
times or more will reset the current aircraft position as a new home point of PHANTOM 2 VISION
+
.
Failsafe on the DJI VISION App
The DJI VISION App will provide information during Failsafe.
Control Signal Lost Indicator
Going Home Indicator
4.3 Regaining Control During Failsafe Procedure
Position of Switch S1
