dji Phantom 2 Vision + - Shutter Button

©2014 DJI Innovations. All Rights Reserved.58 |
(3) Micro-SD card is damaged.
(4) Connection between the DJI VISION App and camera is broken.
[10]Shutter Button
Tap to take photos.
Single capture: press once for a single capture.
Continuous capture: press once for 3 or 5 captures.
Timed capture: press once to begin a timed capture, press again to stop.
(1)
(2)
Shutter button is disabled during video recording.
Capture modes can be reconfigured in camera settings; refer to the<Camera Settings>.
[11]V i de o RecordingButton
Start and stop video recording. Tap once to start recording. Are d do t will blink to indicate recording is in
progress and a time c o de will appear in the top right corner of the preview screen. Press again to
stoprecording.
[12] Camera Settings
Tap to open the camera settings menu, refer to <Camera Settings>.
[13]Hide or Show Flight Parameters.
Tap t o h i de the flight parameters. Tap again to show.
