dji Phantom 2 Vision + Manual

©2014 DJI Innovations. All Rights Reserved.35 |
position. Users should follow their loc a l regulations accordingly.
FCCCE
（
1
）
When adjusting the potentiometer knob to i ts limit position, be very careful to prevent
damaging the potentiometer knob. Do not apply too much force during this adjustment. Also be
sure to use the correct sized screwdriver.
（2） CE compliant devices have an effective communication range of 300 meters in open spaces due
to power limitations. Be sure to watch your fight distance as the PHANTOM 2 VISION+will
enter Failsafe mode (auto-landing or go home and land) if it fliesbeyond this range.
（3） FCC compliant devices have an effective range of 500 meters in open spaces. Be sure to watch
your fight distance as the PHANTOM 2 VISION+will enter Failsafe mode (auto-landing or go
home and land) if it fliesbeyond this range.
（
4
）
Pay attention to and follow local laws and regulations.
（
1
）
The remote controller comes set for CE compliance up delivery as the default setting.
（2） It is recommended to use a flathead screwdriver of Φ2.4mm for adjustment.
（
3
）
There is another potentiometer reserved.

dji Phantom 2 Vision + Specifications

General

Camera Resolution	14 MP
Flight Time	25 minutes
Max Speed	15 m/s
Max Ascent Speed	6 m/s
Max Descent Speed	2 m/s
GPS	Yes
Gimbal	3-axis
Battery Capacity	5200 mAh
Diagonal Motor-to-Motor Distance	350 mm
Transmitter Frequency	2.4 GHz
Battery Voltage	11.1 V
Video Resolution	1080p at 30fps, 720p at 60fps
Control Range	700 meters
Battery	3S LiPo
Operating Temperature	-10°C to 50°C
Video Recording Modes	1080p30 / 720p60
Transmitter Range	700 meters
Max Flight Distance	700 meters
Weight	1242 g
Charging Time	90 minutes
