dji PHANTOM 4 PRO User Guide

It’s important to understand basic flight guidelines, for the safety of both you and those around you. Don’t
forget to read the Disclaimer and Safety Guidelines.
Specifications
Aircraft
Weight (Battery & Propellers Included): 1375 g
Max Ascent Speed: S-mode: 6 m/s; P-mode: 5 m/s
Max Descent Speed: S-mode: 4 m/s; P-mode: 3 m/s
Max Speed: 45 mph (72 kph) (S-mode); 36mph (58 kph) (A-mode); 31 mph (50 kph) (P-mode)
Max Service Ceiling Above Sea Level: 19685 ft (6000 m)
Max Flight Time: Approx. 30 minutes
Operating Temperature: 32° to 104° F ( 0° to 40° C)
GNSS: GPS+GLONASS
Operating Frequency: 2.400 – 2.483 GHz and 5.725 – 5.850 GHz
Transmitter Power (EIRP):
2.4 GHz: ≤26 dBm (FCC); ≤20 dBm (CE); ≤20 dBm (SRRC)
5.8 GHz: ≤26 dBm (FCC); ≤14 dBm (CE); ≤26 dBm (SRRC)
Hover Accuracy Range:
Vertical: ±0.1 m (With Vision Positioning); ±0.5 m (With GPS Positioning)
Horizontal: ±0.3 m (With Vision Positioning); ±1.5 m (With GPS Positioning)
Gimbal
Controllable Range: Pitch: -90° to +30°
Vision System
Velocity Range: ≤31 mph (50 kph) at 6.6 ft (2 m) above ground
Altitude Range: 0 – 33 ft (0 – 10 m)
Operating Range: 0 – 33 ft (0 – 10 m)
Obstacle Sensory Range: 2 – 98 ft (0.7 – 30 m)
Operating Environment: Surfaces with clear patterns and adequate lighting (> 15 lux)
Infrared Sensing System

dji PHANTOM 4 PRO Specifications

General

Type	Quadcopter
Product color	Grey, White
Maximum speed	6 m/s
Frequency band	2.400 - 2.483 GHz, 5.725 - 5.825 GHz GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	42 °
Maximum flight time	30 min
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.1 m
Horizontal hover accuracy	0.3 m
Maximum operating distance	6000 m
Maximum pitch angular velocity	250 °/sec
Battery voltage	15.2 V
Battery capacity	5870 mAh
Transmitter battery capacity	6000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1280 x 720, 1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	30 fps
Optical sensor size	1 \
Camera shutter speed	8 - 1/2000, 8 - 1/8000 s
Image formats supported	DNG, JPG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum video resolution	4096 x 2160 pixels
Field of view (FOV) angle	70 °
Bitrate at maximum video resolution	100 Mbit/s
Operating temperature (T-T)	0 - 40 °C
Built-in processor	-
Operating frequency	2.4 - 2.483 MHz
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Moving control functions	Backward, Downward, Forward

Weight and Dimensions

Battery weight	468 g
