Compass Calibration
LED Flashing
Begin horizontal calibration
Begin vertical calibration
Calibration or others error
ESC Sound Introduction
ESC State
Sound
Ready
♪1234567
Throttle stick is not at bottom
BBBBBB…
Input signal abnormal
B--------B--------B…
Input voltage abnormal
BB---BB---BB---BB…
Transmitter State Introduction
Transmitter State
Introduction
The throttle stick isn’t at the lowest position after turning on may alarm.
B--------BB
Linking between the Transmitter and the Receiver
Normal Operation
Low-battery Alert (Need to change the battery)
BB…………
Specifications of the Aircraft
Parameters
Range
Operating Temperature
-10°C ~ 50°C
Power Consumption
3.12W
Supported Battery
ONLY 3S LiPo
Take-off Weight
<1200g
Hovering Accuracy (GPS Mode)
Vertical: ± 0.8m. Horizontal: ± 2.5m
Max Yaw Angular Velocity
200°/s
Max Tilt Angle
35°
Max Ascent / Descent Speed
6m/s
Max Flight Velocity
10m/s
Diagonal distance (motor center to motor center)
350mm
Weight
Weight(with Battery)
670g
800g

dji PHANTOM Specifications

General

Megapixel	14 MP
Supported video modes	1080i, 1080p, 720p
Battery capacity	5200 mAh
Product color	Red, White
Frequency band	5.728－5.85 GHz
Maximum operating distance	400 m

Weight and Dimensions

Weight	1284 g
