dji RC Pro Installation Guide

1. Antennas
2. Back Button/Function Button
3. Control Sticks
4. RTH Button
5. Flight Pause Button
6. Flight Mode Switch
7. 5D Button
8. Power Button
9. Conrm Button/Customizable C3 Button
10. Touchscreen
11. microSD Card Slot
12. USB-C Port
13. Mini HDMI Port
1
2
3
4
5
10
11
12
13
6
7
8
9
Overview

dji RC Pro Specifications

General

Compatibility	Mavic 3
Product color	Black
Brand compatibility	DJI
Operating temperature (T-T)	-10 - 40 °C
Quantity per pack	1 pc(s)
Built-in display	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Transmission distance	15000 m
Battery life	3 h
Battery type	Built-in battery
Battery voltage	7.2 V
Battery capacity	5000 mAh
Battery recharge time	2 h

Weight and Dimensions

Depth	137.41 mm
Width	183.27 mm
Height	47.6 mm
Weight	680 g
