ROBOMASTER EP Core User Manual
Robot and Third-Party Platforms
The robot is compatible with third-party platforms. Third-party platforms are powered by the power
connector module and communicate with the robot using the SDK protocol. For more information,
visit robomaster-dev.rtfd.io.
There are two ways to connect the robot with third-party platforms:
a) UART Connection
The third-party platform Arduino
TM
connects with the power connector module and communicates
with the robot via the UART port of the motion controller as shown below:
The third-party platform Micro:bit
TM
connects with the power connector module and
communicates with the robot via the UART port of the motion controller as shown below:
0 1 2 3V CND
