dji Robomaster EP Core - Product Profile; Introduction; Robot Diagram

6
©
2020 DJI All Rights Reserved.
Product Prole
Introduction
The RoboMaster S1 Education Expansion Set Core (EP Core) is an all-in-one education solution
for STEAM classrooms. It provides an official SDK that can be used with powerful mechanical
accessories and interfaces to expand hardware possibilities. Together with rich teaching resources
and a continually-updated competition database, the EP Core delivers a new classroom experience
to make education easier for both teachers and students, expanding the boundaries of the future of
education.
Robot Diagram
1. Chassis
2. Right-Threaded Mecanum Wheel
3. Chassis Front Armor (built-in Hit Detector)
4. Left-Threaded Mecanum Wheel
5. Chassis Left Armor (built-in Hit Detector)
6. Chassis Extension Platform
7. Servo
8. Robotic Arm (1 of 2)
9. Robotic Arm Connecting Rod #1
6
9
8
7
1
15
12
13
14
10
11
2
2
17
16
18
3
5
4
10. Robotic Arm Connecting Rod #2
11. Robotic Arm Connecting Rod #3
12. Robotic Arm (2 of 2)
13. Robotic Arm Endpoint Bracket
14. Gripper
15. Camera
16. Intelligent Controller
17. Intelligent Controller Antenna
18. Rear Extension Platform
