dji RONIN 4D Quick Start Guide

EN
©
2021 DJI OSMO All Rights Reserved.
1
DJI Ronin 4D Quick Start Guide
DJI Ronin 4D Overview
Getting Started
A. Watching the Tutorials
Scan the QR code to watch tutorials on how
to get started with DJI Ronin 4D.
B. Downloading DJI Assistant 2 (Ronin Series)
Visit http://www.dji.com/ronin-4d/downloads to download the
DJI Assistant 2 (Ronin Series) (Windows/Mac) for activating DJI
Ronin 4D.
C. Charging the Battery and Checking the Battery Level
Insert the charging adapter into the battery port and charge the battery with the provided charger. It takes approximately 1.5 hours to fully
charge the battery. When charging or using the battery, the battery level indicators display the battery level. Press the battery level button
to check the battery level when not using the battery.
Power Outlet
100 - 240 V
Tutorials
1. Gimbal and Camera
2. Base Plate
3. Left Hand Grip
4. Top Handle
1
5
6
2 7
3
8
4
5. High-Bright Main Monitor
6. TB50 Intelligent Battery and Battery Compartment
7. Main Body
8. Right Hand Grip
For more information, read the DJI Ronin 4D User Manual: https://www.dji.com/ronin-4d/downloads

dji RONIN 4D Specifications

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
