dji RONIN 4D Quick Start Guide

EN
2
©
2021 DJI OSMO All Rights Reserved.
DJI Ronin 4D Quick Start Guide
Roll Lock
Tilt Lock
Installation
A. Mounting the Lens (Using DL Lens as an example)
1. The gimbal is folded by default. Unfold the roll and tilt axes before mounting the lens. Toggle the roll axis lock to the unlocked position,
adjust the roll axis as shown, and lock the roll axis. Toggle the tilt axis lock to the unlocked position, adjust the tilt axis as shown, and
lock the tilt axis.
2. Press and hold the release button and rotate the DL
mount body cap counter-clockwise to remove.
3. Align the red marks on the lens and the DL mount. Insert and
rotate the lens clockwise until there is a clicking sound.
3
1
2
4
6
5
1
2
1
2
ClickClick

dji RONIN 4D Specifications

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
