DJI Ronin 4D Quick Start Guide

C. Attaching the Hand Grips

Make sure the lever is on the unlocked position at first. Insert the left hand grip into the mounting port on the main body

until there is a clicking

sound and push the lever all the way down

. Attach the right hand grip in the same way.

D. Attaching the Intelligent Battery

Align the Intelligent Battery with the battery compartment and push the battery down until there is a clicking sound.

E. Inserting the Storage Card

Open the card compartment cover and insert a CFexpress2.0 Type B card or mount a DJI PROSSD 1TB card.*

* The CFexpress2.0 Type B card is not included and must be purchased separately. Check the DJI PROSSD Mount User Guide and DJI PROSSD 1TB

User Guide for more information about the DJI PROSSD 1TB card.

ClickClick

Other manuals for dji RONIN 4D

Questions and Answers:

Need help?

Do you have a question about the dji RONIN 4D and is the answer not in the manual?

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
