DJI RSC 2
Quick Start Guide
Button Functions
* The camera control cable must be connected in order to use the functions of the camera control button
and front dial. Note that these functions will vary according to the camera. Refer to the DJI RSC 2 Camera
Compatibility List on www.dji.com/rsc-2 for more information.
3D Roll 360: enable to shoot footage while rotating the camera 360°.
Portrait: enable to shoot in portrait mode.
Custom: enable or disable any axis follow as required.
Follow Speed: select the follow speed.
M Button
Tap to select a user prole.
Press and hold to enter Sport mode.
Press and hold and press the trigger twice to remain in Sport mode. Repeat to
exit Sport mode.
Quickly tap twice to enter portrait mode.
Press three times to enter or exit 3D Roll 360. When in 3D Roll 360, move the
joystick left or right twice to automatically rotate the camera. Tap the trigger
twice to stop continuous auto rotation.
Press and hold the M button together with the trigger to begin auto tune.
Trigger
Tap once to start ActiveTrack (requires the Ronin RavenEye Image
Transmission System to be enabled).
Press and hold to enter Lock mode.
Tap twice to re-center the gimbal.
Tap three times to turn the gimbal 180° so that the camera faces you (sele mode).
Camera Control Button*
Press halfway for autofocus.
Press once to start or stop
recording.
Press and hold to take a photo.
Front Dial*
Turn to control focus (default
setting).
Power Button
Press and hold to power on or
o.
Tap or press twice to enter or
exit sleep mode.
Joystick
Push up or down to control
the movement of the tilt axis
and left or right to control the
movement of the pan axis
(default setting).
