EN
8
©
2020 DJI OSMO All Rights Reserved.
DJI RSC 2
Quick Start Guide
3. Balancing the Roll Axis
a. Unlock the roll axis. Loosen the knob on the roll arm
1
.
b. Check the direction in which the roll motor swings. If the camera rotates to the left,
move the camera to the right
2
. If the camera rotates to the right, move the camera to
the left
2
.
c. Tighten the knob. The roll axis is balanced when the camera is steady.
d. Lock the roll axis.
2. Balancing Depth for the Tilt Axis
a. Rotate the tilt axis so that the camera lens is pointing forward. Toggle the lever to the
unlocked position
1
.
b. Check to make sure the camera is not front or back-heavy. If front-heavy, move the
camera backward
2
. If back-heavy, move the camera forward
2
.
c. Toggle the lever to the locked position. The tilt axis is balanced when the camera is
steady while tilted up or down by 45°.
d. Lock the tilt axis.
1
2
1
2
To Next Page
