dji Thumb Controller - External Receiver (for Ronin Only)

6
©
2015 DJI. All Rights Reserved.
[5] Micro-USB Port
For charging the Thumb
Controller and upgrading its
rmware
[6] Override Button
Allow the Thumb Controller
to reactivated and updated
following a failure update
process
[1] CAN Port
Connects the receiver to the
Ronin
[2] Bind Button
Connects the Thumb
Controller to the Ronin
[3] LED Indicator
Indicates the status of the
receiver
[4] Micro-USB Port
For upgrading the rmware
External Receiver (For Ronin Only)
[5]
[6]
[1]
[2]
[3]
[4]
