DK-1100A Ink Roll Coder Operation Manual
2.4 Machine Specifications
Print Area Axial = 40mm
Radial = 45.5mm
Printing Lines T-type (axial) up to 13lines, max. 20 characters per line
R-type (radial) up to 10lines, max. 13characters per line
Font Size T-type 1.5 mm 2.0 mm 2.5 mm, 3.0mm * 3.5mm
R-type 3.5mm*3.5, 4.5, 5.5mm
special letters and font can be custom-made
Cycle Rate up to 300 prints/ minute
Surface Speed up to 35 meters/ minute
Pouch Length 38mm 4-up printer
75mm 2-up printer
Type of Print Head Right-hand (Clockwise
Left-hand (Counter-clockwise)
Control Box LED display
Ink Roll Required Ö36*40 mm
Electrical AC100-AC230V 50/60 Hz
Power 130W 2A Fuse
Environmental Operating Temperature 4 -40
Relative Humidity 10%-95%
Weight Print Head 2.0kg Control Box 1.0kg
Dimensions Print Head 120mm*100mm*170mm (L*W*H)
Control Box 180mm*180mm*102mm (L*W*H)
