DK-1100A Ink Roll Coder Operation Manual
6. SCHEMATICS AND PARTS ILLUSTRATIONS
Item No .
Quantity
Part No .
Description
1
2
3
4
5
6
7
8
9
10
11
1
1
1
1
1
1
1
1
1
1
1
C9901000A
C9900070A
C9900007
C9900072
Y9900005
Y9900012
C9900010
C9900011NP
C9900009
C9900074A
C9900071
DK-1100A Control Box
Main Control PCB
7-pin Drive Cable
Power Plug
7-pin Navigate Plug
3-pin Navigate Plug
Power Cable
Proximity Sensor NPN
3-pin I/O Cable
Operation Panel
LED Display
