v.210818 | 5
ASSEMBLY
STEP BY STEP INSTRUCTIONS
STEP 2: REAR WHEELS
1. Remove all hardware from the axle.
2. Install the wheel with stem facing out, then large washer, then nut. Turn by hand to tighten,
back o nut to align hole, insert the pin and secure as shown.
3. Align the wheel cap in the groove and tap lightly with a rubber mallet or a block of wood and
hammer until seated evenly into the groove.
NOTE: Your chipper tires are D.O.T. approved, but only for street towing. This unit is not build
for highway towing. Tires are rated for 45 mph (72 km/h).
ASSEMBLY STEPS AS SHOWN
1. Install wheel with valve stem on the outside
2. Washer
3. Nut
4. Pin
5. Cap
1
2 3 4 5
ENGLISH
