12 | OPC513 man.
OPERATION SAFETY
Operate the equipment from within the green operator zone as shown in the diagram below,
avoid the dotted red zones as they represent both feed chutes and expulsion chutes.
DANGER! FAILURE TO OPERATE THE EQUIPMENT IN THIS POSITION CAN RESULT IN
SERIOUS INJURY OR DEATH.
ITEM # DESCRIPTION
1 Operator Zone
2 Feed Chute
3 Engine
4 Foot Plate
5 Expulsion Chute
DANGER
• Make sure the operator knows how to stop and disengage the equipment before
operating.
• Do not place hands in the feed chute during operation. Serious injury or death could
result.
• Do not straddle or step over the equipment during operation.
• Do not move the equipment while the engine is running.
• Never leave the equipment unattended while the engine is running. Shut o the
engine even if you are leaving the equipment for a short period of time.
• Avoid contact with the muer and other hot areas of the engine during operation or
after running to prevent burns.
1
4
3
2
2
5
ENGLISH
