18 | OPC566E man.
SAFETY & OPERATION
YOUR KOHLER ENGINE
1 Air Filter - Summer and Winter Positions
2 Choke - Left is On / Right is O (Run Position)
3 Gas - Use Mid Grade or Higher
4 Gas On / O Switch - Left is O / Right is On
5 Throttle - Rabbit Fast / Turtle Slow
6 Pull Starter - Pull Tight - Then Pull Start
7
Oil - Fill to mark 10W30, will not start if oil is low, has low oil shuto
protection. Two yellow caps are oil fill caps, use either one to fill oil.
2
1
5
3
4
6
7
