30 | OPC566E man.
No. Specification No. Specification
1 Rubber Fixer Strip 41 Dust Cap
2 Kill Switch Cover 42 M24 x 1.5 Slotted Nut
4 Rubber Plate 46 Rear Wheel Axle
8 In-Feed Hopper 47 Bearing F207
10 Seal Cover (Left) 48 Roller
11 In-Feed Damping Rubber 49 Blade
12 Engine (Recoil/Electric Start) 51 Anvil
13 Engine Fixture Plate 52 Anvil Fixture
14 Main-Frame 53 Battery Fixture
15 Spacer dia. 35 x dia. 45 x 10 54 Battery Box
17 Buckle 55 Battery 12V20AH
18 Seal Cover (Right) 56 Bearing Cover
19 Belt Inner Cover 61 V-Belt 17 x 1143
20 Discharge Damping Rubber 62 Engine Pulley
21 Arch Plate 63 Roller Pulley
22 Front Wheel Frame 64 Belt Cover
23 Front Wheel Rotation Frame 66 Fore-Wheel Fixing Frame
24 M10 Screw and Nut 67 Tire 4.8-8
25 M10 Locknut 68 Press Switch
26 Axle Cover 69 Switch Base
27 Bearing 6204
28 M24 x 1.5 Slot Nut
29 Tow Bar
30 Tow Hitch
31 Chain
32 Deflector
33 Discharge (Top Part)
34 Discharge (Middle Part)
35 Discharge (Bottom Part)
36 Spacer dia. 21 x dia. 25 x 95
37 Fore-Wheel Fixture
38 Wheel 4.10-4
39 Washer dia. 16 x dia. 26 x 3
40 Screw M16 x 12
Scan here to access the DK2 POWER
Parts Store or open your browser and go to
www.detailk2.com/shop-power-equipment-parts
Your Wood Chipper model is: OPC566E
PARTS & SCHEMATICS
PARTS LIST
