26 | OPC566E man.
IN-FEED
SAFETY & OPERATION
OPERATION GUIDELINES
STOPPING THE WOOD CHIPPER
1. Press the safety shut-o bar on the feed chute.
OR
2. Move the throttle lever to “IDLE”.
3. RECOIL START: Slide the gas lever to the left to shut engine o.
4. ELECTRIC START: Turn the key to the “OFF” position.
NOTICE: Wood diameter should be no bigger than 6 inches.
NOTE: If the drum jams with wood under the drum, remove the drum shaft side shield and
turn the drum counter-clockwise. It may be necessary to remove the drive belts for severe
jams to relieve resistance on the direct drive system to make the drum easier to turn and
free up.
FOOT PLATE
ENGINE
OPERATOR ZONE
OPERATOR ZONE
