Appendix 2: Parts List
Part
No.
Description Qty
Part
No.
Description Qty
1 Bottom Frame 1 60 Running deck cushion 8
2 Main frame 1 61 Square end cap 2 2
3 Upright tube 2 62 Square end cap 3 4
4 Console Frame 1 63 Square end cap 4 2
5 Incline frame 1 64 Hex socket screw M10*55 1
6 Running deck support tube 1 65 Hex socket screw M10*50 4
7 Anti-slip pad 4 66 Hex socket screw M10*40 1
8 Bottom handlebar 2 67 Hex socket screw M10*15 18
9 Front roller 1 68 Hex socket screw M8*50 2
10 Rear roller 1 69 Hex socket screw M8*45 1
11 Cylinder 1 70 Hex socket screw M8*40 5
12L/R Metal speaker grille 1 pr 71 Flat washer Φ10 4
13 Quick button 2 72 Hex bolt M8*25 1
14 Anti-slip pad for tablet holder 1 73 Hex bolt M8*35 1
15 Cross tapping screw ST4*35 4 74 Hex bolt M10*35 4
16 Cross pan head screw M4*8 4 75 Hex socket cap screw M6*45 1
17 Power cable 1 76 Hex socket cap screw M6*55 2
18 Edgings 8 77 Hex socket cap screw M6*12 2
19 Console board 1 78 Hex socket countersunk bolt
M6*30
6
20 Console board bottom cover 1 79 Hex socket countersunk bolt
M6*25
2
21 Console top cover 1 80 Cross tapping screw ST2.2*8 4
22 Console bottom cover 1 81 Cross screw M4*8 4
23L/R Speaker bezel 1 pr 82 Cross screw M5*16 17
24 Bottle holder 2 83 Cross screw M4*12 4
25 Keypad top cover 1 84 Cross screw M5*8 7
26 Keypad bottom cover 1 85 Cross pan head screw M5*25 8
27 Front handlebar top cover 1 86 Cross countersunk head screw
M3*18
2
28 Front Handlebar bottom cover 1 87 Cross tapping screw ST4.0*16 50
29 Safety key mechanism 1 88 Cross tapping screw ST4.0*12 10
30 Safety key clip 1 89 Cross tapping screw ST4.0*12 12
31a/b Left pulse grip sensor 1 pr 90 Cross tapping screw ST2.9*9.5 14
32a/b Right pulse grip sensor 1 pr 91 Lock washer Φ10*1.2 24
33L/R Front handlebar end cap 1 pr 92 Lock washer Φ8*1.2 8
34 Outside upright cover 2 93 Lock washer Φ6*1.2 3
35 Inside upright cover 2 94 Incline motor 1
Part
No.
Description Qty
Part
No.
Description Qty
36L/R Front side cover 1pr 95 Spring washer Φ10 4
37 Motor cover 1 96 Nylon nut M10 10
38 Motor cover design accent L1 1 97 Nylon nut M8 6
39 Motor cover design accent L2 1 98 Nylon nut M6 10
40 Motor cover design accent R1 1 99 Hex nut M3 2
41 Motor cover design accent R2 1 100 AC motor 1
42 End cap 1 101L/R Roller cover 1 pr
43L/R Handlebar 1 pr 102 Inverter 1
44 Side rail 2 103 Computer connecting wire 1
45 Running board 1 104 Upper extension wire 1
46 Circuit breaker 1 105 Lower extension wire 1
47 Running belt 1 106 Controller wire 1
48 Transport wheel 2 107 Safety lock sensor 1
49 Transport wheel cap 2 108 Magnetic sensor 1
50 Flat foot pad 2 109 Cross tapping screw M6*15 2
51 Bafe 1 110 MP3 wire 1
52 Protective plug 4 111 Filter 1
53 Power wire buckle 1 112 Inductor 1
54 Adjusting wheel 4 113 Loudspeaker 1
55 Square end cap 1 2 114 Amplier board 2
56 Power switch 1 115 Audio jack 1
57 Belt 1
58 Plastic pad 2
59 Adjustable front foot 2
