- 15 -
SPECIFICATIONS
7. SPECIFICATIONS
FACTS ABOUT DLS AMPLIFIERS
MODEL Reference 100 Reference 200
Channels 2 4
Mode AB AB
Output power at 13,5 Volt, 20 Hz - 20 kHz with 0,1% THD max:
4 ohm nominal power RMS 2 x 50 Watts 4 x 50 Watts
4 ohm max power RMS 2 x 65 Watts 4 x 60 watts
2 ohm max power RMS 2 x 100 Watts 4 x 80 Watt
4 ohm bridge mode RMS max 220 Watts 2 x 180 Watts
THD < 0,1% < 0,1%
S/N ratio, A-weighted > 100 dB > 100 dB
Damping factor > 200 > 200
Input impedance 15 kohm 15 kohm
Input sensitivity 0,3 - 5,5 volt 0,3 - 5,5 volt
Frequency respone 20 Hz - 20 kHz 20 Hz - 20 kHz
Crossover, highpass 15 - 200 Hz 15 - 200 Hz
Crossover, lowpass 50 - 200 Hz* 50 - 200 Hz*
* Switchable in/out
Filter slope 12 dB/octave 12 dB/octave
Fuses 25 A x 2 25 A x 2
Max kabelare ström: 21 mm
2
21 mm
2
Max kabelarea högtalare 6 mm
2
6 mm
2
Protection circuits Current and thermal Current and thermal
Power consumption:
Idle 0,7 A 1,0 A
Max current 37 A 55 A
Remote 26 mA 26 mA
Dimensions:
Width 290 mm 400 mm
Heigth 65 mm 65 mm
Depth 240 mm 240 mm
Weigth 4 kg 5,4 kg
Use a 2 mm hexagon key for the remote and speaker terminals.
Use a 4 mm hexagon key for the power terminals.
