Specifications
We follow a policy of continuous advancement in
development.
For this reason all or part of specifications & designs
may be changed without prior notice.
15
X-program X-D10 X-D20 X-D25
Number of channels 1 2 2
Power output, 4 ohm (0,1% THD) 180 W 2 x 120 W 2 x 180 W
Power output, 2 ohm (0,2% THD) 330 W 2 x 200 W 2 x 280 W
Power output 1 ohm 590 W
Power output, 4 ohm bridged N/A 1 x 400 W 1 x 550 W
Signal to noise ratio, A-weighted >95 dB >100 dB >100 dB
Damping factor >100 >100 >100
Frequency response 15 Hz - 350 Hz 10 Hz - 35 kHz 10 Hz - 35 kHz
Input impedance, low level 33 kohm 33 kohm 33 kohm
Input impedance, high level 1 kohm 1 kohm 1 kohm
High level input with auto start Yes Yes Yes
Line output (RCA) Yes Yes Yes
Input sensitivity 0,3 - 6V 0,3 - 6V 0,3 - 6V
Bass boost adjustable gain 0 - 18 dB 0 - 18 dB 0 - 18 dB
Filter high pass /subsonic built-in 15-150 Hz* 15-150 Hz*
Filter low pass 50-500 Hz 50-500 Hz* 50-500 Hz*
* can be switched in/out
Phase control 0-180
o
cont. Yes Yes Yes
Power consumption, idle 1,2 A 0,9 A 1,6 A
Fuse 2 x 25 A 1 x 25 A 2 x 25 A
Dimensions HxWxD(mm) 50x298x250 50x258x250 50x298x250
Dimensions (inch) 2x11,8x10 2x10,1x10 2x11,8x10
Weight 3,2 kg 2,8 kg 3,5 kg
X-program X-D30 X-D40
Number of channels 3 4
Power output, 4 ohm (0,1% THD) 2 x 120 W 4 x 110 W
Power output, 2 ohm (0,2% THD) 2 x 200 W 4 x 180 W
Power output, 4 ohm bridged 1 x 310 W 2 x 380 W
Power out mono sub ch. 4 ohm 1 x 220 W N/A
Power out mono sub ch. 2 ohm 1 x 330 W N/A
Signal to noise ratio, A-weighted >100 dB >100 dB
Damping factor >100 >100
Frequency response 10 Hz - 35 kHz 10 Hz - 35 kHz
Input impedance, low level 33 kohm 33 kohm
Input impedance, high level 1 kohm 1 kohm
High level input with auto start Yes Yes
Line output (RCA) No No
Input sensitivity 0,3 - 6V 0,3 - 6V
Variable phase shift control 0-180 degrees -
Filter high pass all channels - 50 - 500 Hz*
Filter low pass, all channels - 50 - 500 Hz*
Filter high pass front channels 50 - 500 Hz -
Filter low pass, sub channel 30 - 150 Hz -
Subsonic filter stereo channels Fixed 25 Hz / 18 dB Fixed 25 Hz / 18 dB
Subsonic filter mono channel Fixed 25 Hz* -
* can be switched in/out
Bass boost adjustable gain - 0 - 18 dB
Power consumption, idle 1,8 A 1,6 A
Fuse 2 x 25 A 2 x 25 A
Dimensions HxWxD(mm) 50x338x250 50x318x250
Dimensions (inch) 2x13,3x10 2x12,5x10
Weight 4,1 kg 3,8 kg
All above output power
ratings at 14,4 VDC
