DMHC TC635 - Assembly

NanJing DMHC Technology Co., Ltd
V
ersion No.
:
V
1.
1
F
ile No.:
D
M
HC
-
TC635
Prepared: Li Lulu Revised： Wang Xiaolei Approval： Sun Min
Date: 2022-6-21 Date： 2022-6-28 Date： 2022-6-28
3
4). Assembly
① Fix the display in a suitable position on the handlebar. Then adjust the angle of the auxiliary switch to make
it easier to watch and use when riding. (Applied to outer diameter of 22.2-31.8 mm.)
② Fix and tighten the bolt with a hex key (M3*12, stainless, GB/T70.1-2008), the locking torque 1 N·m.
③ Fix the remote in a suitable position on the handlebar. Then adjust the angle of the auxiliary switch to make
it easier to watch and use when riding. (Applied to outer diameter of 22.2mm.)
