5. SCOPE OF SUPPLY
1
CSD-36X
1 pc.
2 USB Type-C cable 1 pc.
3
Attachment (bit) PH1 + PH2
110 mm
1 pc.
4
Attachment (bit) PZ1 + PZ2
110 mm
1 pc.
5 Attachment (bit) HEX4 65 mm 1 pc.
6 Attachment (bit) PH0 65 mm 1 pc.
7 Attachment (bit) SL4 65 mm 1 pc.
8 Attachment (bit) T10 65 mm 1 pc.
9 Attachment (bit) T20 65 mm 1 pc.
10
The original safety and
operating instructions
1 pc.
11 Covering 1 pc.
12 Packaging 1 pc.
6. INTENDED PURPOSE
AND APPEARANCE OF THE
ELECTRICAL TOOL
Intended purpose
Accumulator screwdriver (hereinafter re-
ferred to as "power tool") is intended for
screwing and unscrewing screws, bolts,
and nuts. All other uses are prohibited.
The electric tool has a plastic case with
a comfortable rubberized handle, which
ensures a reliable hold during work. The
on when the screw-in or unscrew-out
switches are pressed, which adds con-
venience in low-light conditions. A USB
Type-C connector is built into the case,
which is designed for connecting a USB
cord and charging the power tool.
The principle of operation of the power
tool: when the switch is pressed, it turns
on.
Appearance (Fig. 1)
1 Handle
2
Charger cord connector (USB
Type-C)
3 Charge indicator
4 Unscrewing switch
5 Screwing switch
6 Flashlight
7 Chuck
WARNING!
LLC "DNIPRO M" constantly works
on improving its products and in
this regard reserves the right to
make changes to the appearance,
design, equipment and content of
the original instructions for safety
and operation of the power tool,
without notifying consumers. All
possible changes will be aimed only
at the improvement and moderniza-
tion of the electric tool.
7. TECHNICAL SPECIFICATIONS
Parameters Unit of Measure CSD-36X
Rated voltage V 3.6
Rated accumulator capacity mAh 850
Accumulator type Li-Ion
Rated charging voltage V 5
Rated charging current Ah 1
Maximum electrical torque N·m 1,2
Maximum manual torque N·m 8
The number of rotation speeds 1
Idle speed n0 min
-1
280
HEX chuck type mm 6.35
