DNT DigiMicro Profi HDMI - Connecting to TV;Monitor; Capture a Photo; Connecting to PC

English
- 30 -
Connect DigiMicro Profi HDMI to TV/Monitor with HDMI cable
Connect the microscope to TV or monitor with the HDMI cable.
Power the microscope with the supplied power adaptor.
Turn on the power of the microscope with the -button.
Turn on the power of the TV/monitor and select HDMI input.
Capture a photo
In the supplied condition you are able to watch items. To capture photos insert a microSD card
into the card slot.
Turn the on-screen display on/off with the -button.
Turn the Focus Wheel to focus the image of your object to its best focus and press
button to capture and store a photo.
Playback
The playback works if a microSD card is inserted in the card slot. Before inserting
the card turn the microscope off.
Press the MODE-button to switch to playback mode.
The -icon at the left upper edge shows the playback mode.
Press the -button to show the previous captures photos.
Connect the DigiMicro Profi HDMI to the computer
The device has 2 modes to get connected to the computer. In both modes plugin the device
with the USB port of the computer. If it is connected for the fi rst time it takes a while to install
the drivers.
1. Mass Storage
Capture photos and store them on the microSD card. If the SD card is located in the card slot
the device is setup as a mass storage device when connected to the computer. To edit the
photos with the supplied software you need to import thes photos into the photo folder which
is setup in the PortableCaptureHD software.
2. Preview on PC
Works only with the software installed. Remove the microSD card from the slot. Connect the
microscope to the USB port of the computer. After a few seconds the computer installs an
imaging device. You can control the correct setup in the device manager (Windows). Start the
PortableCaptureHD setup the resolutions VGA or HD and you have a preview.
Operation
