F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 6-19
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Over Temperature
or fuse blown (I
AMP#0) SLOT 5
Current amplifier in slot 5 is
overheated or has a blown fuse.
Replace the current amplifier
board in slot 5 (refer to ”Circuit
Board Replacement”
on page 7-17).
Over Temperature
or fuse blown (I
AMP#1) SLOT 6
Current amplifier in slot 6 is
overheated or has a blown fuse.
Replace the current amplifier
board in slot 6 (refer to ”Circuit
Board Replacement”
on page 7-17).
Over Temperature
or fuse blown (I
AMP#2) SLOT 7
Current amplifier in slot 7 is
overheated or has a blown fuse.
Replace the current amplifier
board in slot 7 (refer to ”Circuit
Board Replacement”
on page 7-17).
Over Temperature
or fuse blown (V
AMP#0) SLOT 8
Voltage amplifier in slot 8 is
overheated or has a blown fuse.
Replace the voltage amplifier
board in slot 8 (refer to ”Circuit
Board Replacement”
on page 7-17).
Over Temperature
or fuse blown (V
AMP#1) SLOT 9
Voltage amplifier in slot 9 is
overheated or has a blown fuse.
Replace the voltage amplifier
board in slot 9 (refer to ”Circuit
Board Replacement”
on page 7-17).
Over Temperature
or fuse blown (V
AMP#2) SLOT 10
Voltage amplifier in slot 10 is
overheated or has a blown fuse.
Replace the voltage amplifier
board in slot 10 (refer to ”Circuit
Board Replacement”
on page 7-17).
Missing analog I/O
board
Hardware is missing or not
communicating properly with
the CPU.
Check the communication cable. If
OK, replace the analog I/O board
in slot 4 (refer to ”Circuit Board
Replacement” on page 7-17).
Table 6.7 System Errors (Continued)
Error Explanation Action
