19. Click the Enable button for current source I1.
The button turns green to indicate the source is enabled.
WARNING The high intensity yellow LED flashes when the battery simulator or any
output source is on or enabled to indicate the potential for dangerous or
fatal voltages.
20. Click System Output to turn I1 on.
The System Output button turns red and the timer starts. When the
relay responds, the timer stops and the elapsed time appears in the
field for Timer 1. System Output is automatically switched off when
the timer stops.
21. Click Reset to reset Timer 1 to 0.00.
