Cavity
Cartridge
Fuse / Relay
Mini Fuse Description
12 40 Amp Green JB Feed / EBL
/TCase
Brake
13 30 Amp Pink JB Feed RR
14 40 Amp Green ABS Pump
15 50 Amp Red JB Feed
16 10 Amp Red Crank
17 Spare
18 20 Amp Yellow Fuel Pump
19 20 Amp Yellow NGC
20 Spare
21 20 Amp Yellow ABS Batt
22 20 Amp Yellow NGC Batt
23 20 Amp Yellow Trailer Tow
24 15 Amp Blue A/C Clutch
25 15 Amp Blue JB Feed Stop
26 Spare
Cavity
Cartridge
Fuse / Relay
Mini Fuse Description
27 10 Amp Red JB Feed Acc #
1
28 Spare
29 Relay Run Start
30 Relay Run Remote
31 Spare
32 Relay Starter
33 Relay ETAX
34 Relay AC Clutch
35 Relay Fuel Pump
Rly
36 Spare
37 Spare Brake Supres-
sion
38 Spare
39 Relay Blower Motor
40 Relay ASD Rly
374 MAINTAINING YOUR VEHICLE
