Dodge 2006 Durango - Underhood Fuses (Integrated Power Module)

Underhood Fuses (Integrated Power Module)
Cavity
Cartridge
Fuse / Relay
Mini Fuse Description
1 Relay Wiper On/Off
Rly
2 Relay Wiper Hi/Lo
Rly
3 Relay Horn Rly
4 Relay Rear Wiper
Rly
5 Relay Lt T-Tow
Stop/Turn Rly
6 Relay Rt T-Tow
Stop/Turn Rly
7 Relay Park Lamps
Rly
8 10 Amp Red Lt Park Lamps
9 10 Amp Red T-Tow Park
Lamps
10 10 Amp Red Rt Park Lamps
Cavity
Cartridge
Fuse / Relay
Mini Fuse Description
11 Relay Rad Fan Hi
Rly
12 20 Amp Yellow FCM Batt #4
13 20 Amp Yellow FCM Batt #2
14 20 Amp Yellow Adjustable
Pedal
15 20 Amp Yellow Ft Fog Lamps
16 20 Amp Yellow Horn
17 20 Amp Yellow Rear Wiper
18 20 Amp Yellow FCM Batt #1
19 20 Amp Yellow Lt T-Tow
Stop/Turn
20 20 Amp Yellow FCM Batt #3
21 20 Amp Yellow Rt T-Tow
Stop/Turn
22 30 Amp Pink FCM BATT # 5
23 40 Amp Green Rad Fan
MAINTAINING YOUR VEHICLE 375
7
