Interior Fuses
The interior fuses are located on the drivers side under the instrument panel.
Cavity Cartridge Fuse Mini Fuse Description
F1 – 20 Amp Yellow Front Heated Seats – If Equipped
F2 – 20 Amp Yellow Rear Heated Seats, Heated Steering Wheel – If Equipped
F3 – 10 Amp Red Park Assist Module, Rear Camera, Left and Right Blind Spot
Sensor, Compass – If Equipped
F4 – 15 Amp Blue Instrument Cluster
F5 – 10 Amp Red HVAC, Humidity Sensor, In-Vehicle Temperature Sensor, In-
side Mirror Assembly
F18 – 15 Amp Blue Radio
F20 – 10 Amp Red Steering Column Control Module, Switch Bank
F21 – 10 Amp Red Diagnostic Port
F22 – 10 Amp Red Universal Garage Door Opener, EOM
F23 – 20 Amp Yellow Sunroof
610 MAINTAINING YOUR VEHICLE
