Cavity Maxi Fuse Mini Fuse Description
F19 – 10 Amp Red A/C Compressor Clutch
F20 – 30 Amp Green Rear Defroster (EBL)
F21 – 20 Amp Yellow Fuel Pump
F22 – 10 Amp Red Occupant Restraint Controller
F23 – 25 Amp Clear Brake System Module
F24 – 20 Amp Yellow Engine Control Module, Fuel Injectors
F30 – 20 Amp Yellow Power Outlet (Console)
F81 60 Amp Blue – Interior PDC Battery Feed, Power Seats
F82 30 Amp Green – Amplifier
F83 40 Amp Orange – HVAC Blower Motor
F84 – 20 Amp Yellow Cigar Lighter
F85 – 10 Amp Red Sunroof, LRSM, Power Outlet (Console),
UCI/AUX Port, Cigar Lighter
F86 – 20 Amp Yellow –
7
MAINTAINING YOUR VEHICLE 613
