Cavity Maxi Fuse Mini Fuse Description
F01 70 Amp Tan – Body Control Module #1
F02 60 Amp Blue – Body Control Module #2
F03 30 Amp Green – Output For Starter Relay #1
F04 40 Amp Orange – ESC Pump Motor
F05 40 Amp Orange – Transmission Control Module #1
F06 30 Amp Green – Body Control Module #3
F07 40 Amp Orange – EBL RLY Coil, Blower Motor RLY Coil
F09 – 5 Amp Tan Radiator Fan
F10 – 10 Amp Red ORC
F11 – 20 Amp Yellow Run/Start, Engine Control Module
F14 – 15 Amp Blue Transmission Control Module #2
F15 – 15 Amp Blue Transmission Control Module #3
F16 – 15 Amp Blue Engine Control Module, Ignition Coils
F17 – 15 Amp Blue Brake System Module
F18 – 20 Amp Yellow Engine Control Module
