Cavity Maxi Fuse Mini Fuse Description
F87 – 10 Amp Red Wastegate, Purge Solenoid, OBD Vent
Valve, Oxygen Sensor Heaters
F88 – 10 Amp Red Heated Outside Mirrors
Body Control Module (BCM) Fuses
Cavity Cartridge Fuse Mini Fuse Description
F12 – – Spare
F13 – 15 Amp Blue Left Headlamp
F31 – – Spare
F32 – 10 Amp Red Interior Lighting/Decklid/Liftgate Release
F33 – 25 Amp Clear Window Motor – Driver
F34 – 25 Amp Clear Window Motor – Passenger
F36 – 15 Amp Blue Intrusion Module
F37 – 10 Amp Red Instrument Panel Cluster
F38 – 20 Amp Yellow Door Locks
632 MAINTAINING YOUR VEHICLE
