TR AILER TOWING WEIGHTS (MA XIMUM TRAILER WEIGHT RA TINGS)
Engine/Model Model
GCWR (Gross Combined Wt.
Rating)
Frontal Area
Max. GTW (Gross Trailer
Wt.)
Max. Trailer Tongue
Wt. (See Note)
3.6L 4x2 8,900 lbs (4 037 kg) 40 sq ft (3.72 sq
m)
5,000 lbs (2 268 kg) 500 lbs (227 kg)
3.6L 4x4 8,900 lbs (4 037 kg) 40 sq ft (3.72 sq
m)
5,000 lbs (2 268 kg) 500 lbs (227 kg)
5.7L 4x2 13,100 lbs (5 942 kg) 60 sq ft (5.57 sq
m)
7,400 lbs (3 357 kg) 740 lbs (336 kg)
5.7L 4x4 13,100 lbs (5 942 kg) 60 sq ft (5.57 sq
m)
7,200 lbs (3 266 kg) 720 lbs (327 kg)
Refer to local laws for maximum trailer towing speeds.
NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed
the weight referenced on the Tire and Loading Information placard.
UTILITY
56
