Cavity Relay Cartridge Fuse Mini-Fuse Description
39 — — 10 Amp Red HVAC Module, In Vehicle Temp, Blower Relay
40 — — — Not Used
41 G8VA — — Run/Start
42 G8VA — — Fuel Door
43AC (For-
ward Fuse)
— — 2 Amp Grey SCCM
43BE (Rear-
ward Fuse)
— — 10 Amp Red Tire Pressure Module
44AC (For-
ward Fuse)
— — 10 Amp Red Rear View Mirror, Aux Port Jumper
44BE (Rear-
ward Fuse)
— — 10 Amp Red Intelligent Battery Sensor
45 — — 10 Amp Red PCM-Powertrain Control Module, Fuel Pump Relay
46 — — 10 Amp Red ESC Module, Stop Lamp Switch
47 — — 10 Amp Red ORC Module, Passenger Seat OCM
48 — — 10 Amp Red SCCM
49 — — 25 Amp Clear Amplifier
50 HC Micro — — Rad Fan
51 HC Micro — — Rad Fan Relay SER/PAR
52 HC Micro — — Starter Relay
53 HC Micro — — Rear Window Defroster Relay
54 HC Relay — — Rad Fan Relay High
55 HC Micro — — Wiper ON/OFF
56 HC Micro — — Wiper LO/HI
169
