Vintage-
Drummachine
Gate
Out
12V AC
500mA
Power-
supply
Power-Outlet
Computer
with
Software-Sequenzer
USB
USB MIDI
In
MIDI
In
MIDI-Keyboard
or
MIDI-Drummachine
CV
Out
Clk.
Out/In
MIDI-Synthesizer
CV/Gate-Synthesizer
CV-Keyboard
or
Synthesizer-Module
CV
In
If so desired, please also connect Dark Time’s MIDI-in socket with the MIDI-out socket of e.g.
a suitably equipped computer or drum machine in order to synchronize both machines via
MIDI clock. Please refer to chapter 3.1.4. ”Tempo and Timing” on page 12, and chapter 3.2.
”Synchronization and remote control of Dark Time” on page 15.
• CV/Gate:
You only need to connect at least Gate 1 out and CV1 out jacks to run Dark Time with a CV/Gate-
based synthesizer. Gate triggers the synthesizer envelopes (which, in turn, normally control the
VCF and output VCA), CV1 determines the pitch of the VCO(s).
The Clk In/Out jacks make synchronization with vintage drum machines or sequencers possible
that have not been MIDIed.
Using additional connections, Dark Time will become capable of controlling two analog
synthesizers (or their parameters) in parallel. Also, some of Dark Time’s functions can
be remote-controlled by analog control signals. More about this topic later on in this manual.
The following pictures shows the most importand connections to and from Dark Time:
