DSS200 Hard Drive Replacement Guide DRAFT 0.9 1
DSS200 Hard Drive
Replacement Instructions
ThisdocumentshowsyouhowtoreplaceapermanentlyfailedDSS200internalharddrive
withanewdrive.Pleasereadalltheinstru ctionsbeforeyoubegin.Thedrivereplacement
procedure(Section 1)takesapproximately20minutes.Afterfollowingtheinstructionsin
theRAIDrebuildprocedure(Section 2 ),thesystemcantake
upto10hourstocompletethe
rebuildprocess.
Beforeyoubegin, besureyouhavethefollowing:
• Phillipsscrewdri ver
•Harddrivereplacementkit(DSS200HD ‐SPK)withharddrive(DPN8702640)
IfoneoftheDSS200’sinternalharddrivesfails,itscorrespondingfront‐panelLEDturns
fromgreentored,asshown
intheexampleinFigure 1.
Figure1 
Figure 1 Identifying a Failed Drive in the DSS200
Ifadrivefailswhileashowisrunning,theshowcontinuestorunwithoutinterruption.If
onedrivefails,noinformationislost.Ifaseconddrivefailsbeforeyoureplacethefirst
faileddrive,allinformationislost(andanyshowinprogressstopsrunning).Forthis
reason,you
shouldorreplaceafaileddriveassoonaspossible.
Red LED indicates
failed hard drive
