Rebuilding the RAID with a Replacement Drive
Dolby
®
DSS200 Hard Drive Replacement Guide DRAFT 0.9 5
2 Rebuilding the RAID with a Replacement Drive
TheDSS200musthavefourinternaldrivesinstalledbeforeyoucan runaRAIDrebuild
operation.Thesystempartitionslargerdrivestothesamesizeastheexistinginternal
drives.Therebuildprocesscantakeupto10hours,sobesurenoshowisscheduled,and
nocontentorlicenses
areloadingduringthistime(ifpossible,rebuildinthemorningor
overnight).TorebuildtheDSS200RAIDwithareplacementdrive:
1. PlacetheDSS200inanidlestatebystoppingplaybackofanyshows,andwaitingfor
thecompletionofanyfiletransfersorotheroperations.
2. Besureamonitor
andkeyboardareconnectedtotheDSS 200,thenreconnectthe
power.
3. Ignoretheinitialprompttopress<Alt>+<3>.
4. WhenthesystemrecognizestheRAIDdrives,asshownintheexampleinFigure 8,
press<Alt>+<3>.
Figure8 
Figure 8 RAID Drives Displayed
