Dolmar HT-2145 D - Front and Rear Handle Components; Control Mechanism Parts; Gear and Drive Components; Shear Blade Assembly

Page
Pos.
HT-2145 D
HT-2162 E
Part No. Notes Description Specifications
1 1 1 374 155 000 FRONT HANDLE
1 2 2 381 106 000 NUT M6
1 4 1 382 700 300 REAR HANDLE INC. 5-15
1 5 1 381 508 800 SWITCH ASSY
1 6 1 381 710 800 STOPPER
1 7 1 381 710 500 REAR HANDLE(R)
1 8 1 381 302 300 SPRING
1 9 1 381 710 700 LOCK LEVER
1 10 1 381 302 400 SPRING
1 11 1 381 710 600 THROTTLE LEVER
1 12 1 381 710 400 REAR HANDLE (L)
1 13 1 381 217 500 LABEL
1 14 2 383 040 100 TAPPING SCREW 4X10
1 15 4 381 040 150 TAPPING SCREW 4X15
1 16 1 381 106 000 NUT M6
1 17 1 381 506 055 BOLT M6X55
1 18 1 381 224 600 LABEL
1 19 1 381 506 040 BOLT M6X40
1 20 1 374 136 141 DRUM COMPLETE
1 21 1 381 710 000 CRANK CASE
1 22 2 381 406 016 BOLT M6X16
1 23 2 381 405 000 U-NUT M5
1 24 1 381 500 010 GREASE NIPPLE M6
1 25 2 381 406 035 BOLT M6X35
1 26 2 381 406 001 BALL BEARING UU 6001
1 27 1 381 202 800 SNAP RING
1 28 1 381 610 400 PINION GEAR
1 29 2 381 300 608 BALL BEARING ZZ 608
1 30 1 381 610 300 CRANK GEAR ASSY
1 31 1 381 302 600 SNAP RING
1 32 2 381 611 300 ROD
1 33 1 381 710 200 GASKET CASE
1 34 1 381 710 100 CRANK CASE COVER
1 35 7 381 405 012 BOLT M5X12
1 36 2 381 105 016 SCREW M5-16
1 38 4 381 406 000 U-NUT M6
1 39 1 381 710 300 GUIDE PLATE
1 40 1 381 850 600 STANDARD EQUIPMENT UPPER & LOWER BLADE
1 41 1 381 906 000 WAVE WASHER
1 42 1 381 611 200 FELT
1 43 4 374 008 250 BLADE SLIDING WASHER
1 44 4 381 000 200 SCREW L=19
1 45 1 381 850 600 STANDARD EQUIPMENT UPPER & LOWER BLADE
1 46 1 381 800 208 STANDARD EQUIPMENT BLADE COVER
HT-2145 D
