Dolmar PS-7310 - Cleaning the XD-Air Filter

33
A
Cleaningtheairlter(XD)
9
3
8
2
1
4
5
6 7
8
2
1
5
6 7
9
3
4
CAUTION: To prevent eye injury, always wear eye protection
whencleaningthelterwithcompressedair!
Donotusefueltocleantheairlter
.
Unhook the lter hood clips (1) with the combination tool and
remove the lter hood (2).
Pull out the choke (3) to prevent dirt particles from getting into
the carburetor.
Press together the clip (4) on both sides of the holder (5), unclip
it at the bottom and fold it up.
Remove the XD lter (6) and pull the felt prelter (7) from the
XD lter.
Take the foam lter (8) out of the hood (2).
The lters must be cleaned regularly at least once weekly, and
immediately in the event of poor starting, poor performance, or
increased fuel consumption (replace if necessary).
XDlter:
The XD lter (6) lters the incoming air through a
very ne system of paper ns. It must never be washed out
or cleaned with compressed air!Donottreatwithairlter
oil.
Carefully tap out the XD lter against a clean surface.
ReplacetheXDltereverysixmonths!
Caution: When using compressed air to clean the felt pre-
lter(7),thefoamlterinthehood(8),alwaysuseprotective
eyewear to prevent eye injury!
Donotcleantheairlterwithfuel!
Carefully clean the lters with compressed air, working from
inside to outside.
Caution: Excessive air pressure can destroy the lter. Replace
damaged lters immediately!
Feltprelter(7):
Carefully tap out, or carefully blow out from
the inside with compressed air. Do not use a brush for clean-
ing, since this can press dirt into the fabric. If the lter is very
dirty, wash it out in lukewarm water with regular dishwashing
liquid, and then let it dry thoroughly.
Replace the prelter if cleaning does not result in any detect-
able improvement in performance. Replacetheprelterev-
ery 3 months!
Foamlterinhood(8):
Carefully blow out with compressed
air. If the lter is very dirty, wash it out in lukewarm water with
regular dishwashing liquid.
Push the felt prelter (7) onto the XD air lter (6) and insert the
foam lter (8) into the lter hood (2).
Engage the clip (4) in the rear holder (9) in a vertical position,
place the air lter on the lter bottom, and swing the clip over
the lter base. Push the two ends of the clip together until it can
engage in the two retainers (5) on the lter bottom.
Makesuretheairlterisrmlyattached!
Push in the choke (3) and push the throttle all the way in to
deactivate the half-throttle lock.
Put on the lter hood (2) and hook in the clips (1).
