Dometic ACC3100D User Manual

EN
Symbol Description
Indicates the ventilation system is connected via WLAN.
Controls the dimming of the LED light strips (optional).
Indicates that a solar power source is detected (optional).
Indicates the STORAGE mode is active.
Select the mode.
Indicates an error.
Indicates that the filters needs to be replaced.
Turns the ventilation system on and off.
8 Operation
8.1 Hints for improved use
Observe the following instructions for use to ensure the ventilation system is used efficiently:
• Keep doors and windows closed to minimize energy loss.
• If the vehicle is powered by an internal power source, reduce the power consumption of other equipment to
ensure the longest possible operating time of the ventilation system.
• Select a suitable operation mode and light brightness.
• Ensure that the grilles are not covered.
8.2 Switching on/off
NOTE The ventilation system can give off a slight smell when first used. The smell disappears after a short
time.
Press the button to switch the ventilation system on or off.
8.3 Selecting the mode
The AUTO mode is selected at turn on.
1.
Press the button.
• The indicator lights up.
• The TURBO mode is activated.
2.
Press the button.
• The indicator lights up.
13

Dometic ACC3100D Specifications

General

Brand	Dometic
Model	ACC3100D
Category	Fan
Language	English
