Dometic B59516 Installation Instructions

4
A. Table - Unit Data
Model No. Nominal
Capacity
(BTU HR)
Cooling
Electrical
Rating
Compressor
Rated Load
Amps
Compressor
Locked
Rotor
Amps
Fan Motor
Rated Load
Amps
Fan Motor
Locked
Rotor
Amps
Refrigerant
R-410A
(oz)
Minimum
Wire Size*
AC Circuit
Protection
***Installer
Supplied
Minimum
Generator
Size**
1 Unit / 2 Units
457915.70X 13,500 120 Vac
60 Hz 1 ph
12.4 63.0 2.5 5.8 18.0 12 AWG
Copper
Up to 24'
20 Amp 3.5 kW / 5.0 kW
457915.71X 13,500 12.4 68.0 2.5 5.8 18.0 20 Amp 3.5 kW / 5.0 kW
B57915.71X 13,500 12.4 68.0 2.5 5.8 16.0 20 Amp 3.5 kW / 5.0 kW
B57935.71X 13,500 12.7 68.0 2.7 5.8 16.0 20 Amp 3.5 kW / 5.0 kW
459186.70X 15,000 13.3 66.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
459186.71X 15,000 13.3 70.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
459186E71X 15,000 13.3 70.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
B59186.71X 15,000 13.3 70.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
459196.70X 15,000 13.3 66.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
459196.71X 15,000 13.3 70.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
459196E71X 15,000 13.3 70.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
B59196.71X 15,000 13.3 70.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
459516.70X 15,000 13.3 66.0 2.0 5.6 27.5 20 Amp 3.5 kW / 5.0 kW
459516.71X 15,000 13.3 70.0 2.0 5.6 27.5 20 Amp 3.5 kW / 5.0 kW
459516E71X 15,000 13.3 70.0 2.0 5.6 27.5 20 Amp 3.5 kW / 5.0 kW
B59516.71X 15,000 13.3 70.0 2.0 5.6 27.5 20 Amp 3.5 kW / 5.0 kW
459530.70X N/A 8.6 50.0 2.5 5.8 20.0 15 Amp 2.5 kW / 4.0 kW
B59530.71X N/A 8.6 50.0 2.5 5.8 20.0 15 Amp 2.5 kW / 4.0 kW
B59536.71X 15,000 13.2 70.0 2.7 5.6 22.0 20 Amp 3.5 kW / 5.0 kW
540315.70X 13,500 12.4 63.0 3.0 8.5 18.5 20 Amp 3.5 kW / 5.0 kW
540315.71X 13,500 12.4 68.0 3.0 8.5 18.5 20 Amp 3.5 kW / 5.0 kW
540316.70X 15,000 13.3 66.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
540316.71X 15,000 13.3 70.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
541815A70X 13,500 12.4 63.0 3.0 8.5 18.5 20 Amp 3.5 kW / 5.0 kW
541815A71X 13,500 12.4 68.0 3.0 8.5 18.5 20 Amp 3.5 kW / 5.0 kW
541816A70X 15,000 13.3 66.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
541816A71X 15,000 13.3 70.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
541915A70X 13,500 12.4 63.0 3.0 8.5 18.5 20 Amp 3.5 kW / 5.0 kW
541915A71X 13,500 12.4 68.0 3.0 8.5 18.5 20 Amp 3.5 kW / 5.0 kW
541916A70X 15,000 13.3 66.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
541916A71X 15,000 13.3 70.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
551816.70X 15,000 12.8 60.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
551816.71X 15,000 12.8 70.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
551816A70X 15,000 12.8 60.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
551816A71X 15,000 12.8 70.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
551916A71X 15,000 12.8 70.0 2.8 7.6 29.5 20 Amp 3.5 kW / 5.0 kW
640312.80X 11,000 11.5 53.0 2.6 8.5 20.0 20 Amp 3.5 kW / 5.0 kW
640312.83X 11,000 12.5 63.0 2.6 8.5 18.0 20 Amp 3.5 kW / 5.0 kW
640312C35X 11,000 10.5 53.0 3.5 10.0 19.0 20 Amp 3.5 kW / 5.0 kW
640312C85X 11,000 11.5 53.0 2.6 8.5 20.0 20 Amp 3.5 kW / 5.0 kW
640315.80X 13,500 12.6 63.0 2.6 8.5 18.0 20 Amp 3.5 kW / 5.0 kW
640315.83X 13,500 12.5 63.0 2.6 8.5 19.0 20 Amp 3.5 kW / 5.0 kW
640315.84X 13,500 12.5 63.0 3.5 8.5 19.0 20 Amp 3.5 kW / 5.0 kW
640315C35X 13,500 12.5 61.0 3.5 10.0 17.5 20 Amp 3.5 kW / 5.0 kW
640315C75X 13,500 12.7 52.0 2.6 8.5 14.5 20 Amp 3.5 kW / 5.0 kW
640315C85X 13,500 12.6 63.0 2.6 8.5 18.0 20 Amp 3.5 kW / 5.0 kW
641815.80X 13,500 12.6 63.0 2.6 8.5 19.0 20 Amp 3.5 kW / 5.0 kW
641815C35X 13,500 12.5 61.0 3.5 10.0 17.5 20 Amp 3.5 kW / 5.0 kW
641815C75X 13,500 12.7 52.0 2.6 8.5 14.5 20 Amp 3.5 kW / 5.0 kW
641815C85X 13,500 12.6 63.0 2.6 8.5 19.0 20 Amp 3.5 kW / 5.0 kW
641815H75X 13,500 12.7 52.0 2.6 8.5 14.5 20 Amp 3.5 kW / 5.0 kW
SPECIFICATIONS

Dometic B59516 Specifications

General

Power Source	Electric
Voltage	115V
Hertz	60 Hz
Air Flow	350 CFM
Refrigerant	R-410A
Cooling Capacity	15, 000 BTU
Fan Speeds	3
