Function description CoolFreeze
10
CDF26
Connection socket (fig. 3, page 2) and operating panel (fig. 4, page 2):
Item Description Explanation
1ON
OFF button
Switches the cooler on or off when the button is pressed for
between one and two seconds
2 POWER Status indication
LED lights up green: Compressor is on
LED lights up orange: Compressor is off
LED flashes orange: Display switched off auto-
matically due to low battery
voltage
3 ERROR LED flashes red: Device is switched on but not
ready for operation
4 SET Selects the input mode
Temperature setting
Celsius or Fahrenheit display
Set battery monitor
5 – Display, shows the information
The first three digits of the four-digit display show the
temperature, the fourth digit shows the temperature unit
(°C or °F).
6 UP + Press once to increase the value
7 DOWN – Press once to decrease the value
CDF18-26-36-46--O-16s.book Seite 10 Montag, 7. November 2016 2:13 14
