NL
Het koelaggregaat monteren Koudemachine
166
Legenda bij de afbeeldingen
A
Voor koelaggregaten met klepkoppelingen
Snijd een gat uit met een diameter van ten minste 30 mm (afb. c, pagina 7) voor
de koelleidingen. Gebruik hiervoor een gatenzaag.
Nr. in afb. 8,
pagina 5
Toel ich t i ng
1 Gelijkstroomventilator
2 Thermostaatknop
3 Aansluiting voor gelijkstroomventilator
4 Thermostaat
5 Aansluitkabel
Nr. in afb. 9,
pagina 6
Toel ich t i ng
1 Aansluitkabel
Nr. in afb. 0,
pagina 6
Toel ich t i ng
1 Aansluitkabel
Nr. in
afb. i, pagina 9
en afb. j,
pagina 9
Toel ich t i ng
1 Verbindingsblok
2 Compressor
3 Ventilator
4 Schakelaar afb. i of TEC-regelaar afb. j
LET OP!
Isoleer de wandopeningen en dicht deze na de montage zorgvuldig af
om te voorkomen dat er vocht binnendringt.
