Dometic CT4110 Installation Manual

EN
7
Installing the toilet
Create wall apertures
4.2
The description for the installation of the ser-
vice door can be found in the document sup-
plied
Dometic Seitz SK4, SK5
(
optional/
depending on model).
Make an aperture in the wall for the cassette
with the following dimensions:
for service door
SK4
y= 25 mm (0.98
″
)
; b = 305 mm (12.01
″
)
and
h= 375 mm (14.76
″
)
,
for service door
SK5
y
min
12.5 mm (0.49
=
″
and y
)
max
=
28 mm (1.1
″
;
)
b = 310 mm (12.2
″
and h = 360 mm (14.17
)
″
)
.
The x value results from the toilet installation.
Fig. 5
SK 5
SK 4
Fig. 4
b
h
y
b
h
y
4.2.1
Wall aperture service door
Installing the service door
4.1
Installing the toilet
4.0
1
= Removable cover and seat
= Toilet bowl
2
3
= Emptying blade for the toilet bowl
4
= Console
)
= Level indicator / control panel (flush
5
= Service door
6
Explanation of
3.4
components
Fig. 2
= Emptying blade for the toilet bowl
3
)
= Cassette tank (capacity 19 l / 5.02 US.gal.
7
= Pour out spout
8
= Vent button for emptying
9
Fig. 3
7
3
9
8
2
4
3
1
5
6
